Summit 27.5"

  • 500 Watts Power
  • 13Ah Battery
View specs
Select color: Black with Blue Accents

Battery Capacity

$2,199 $1,499
You save $700 (31%)
Sold out

Example payment is based on the listed product price(s) assuming a 48 month term loan and a 9.99% APR. Subject to approval of credit application. Rates range from 0.00% to 29.99% APR. APRs will vary depending on credit qualifications, loan amount, and term. Bread® pay over time loans are made by Comenity Capital Bank.

Professional In-Store Or Easy DIY Assembly

Choose between:
a) Delivery to your local authorized Magnum Dealer with in-store assembly; or
b) Home delivery & DIY assembly

Expert Service & Support

There are so many ways to get in touch with our Support Team! Chat, call, or drop us an email.

Warranty Protection Up To 5 Years

1-Year limited warranty (included), plus extended product protection plans available for 2, 3 and 5 years

The Magnum Summit 27.5"

The Summit 27 trail/mountain e-bike's stand-out features are the fully integrated battery for a sleek design and a range of accent colors span the top of the down tube. 48v, 500w power system with max speed of 25 MPH with pedal assist and 20 MPH throttle only. The stunning design and high-end components will turn heads.

Highlights

  • Category Mountain
  • Class Can be configured to a Class 1, 2, or 3 E-Bike.
  • Frame Type High-step
  • Seating Active
  • Perfect For Paved / Light Trails / Recreation

THE BATTERY.

The heart of the Magnum Summit is the integrated 48V / 13Ah / 624Wh battery that powers rides up to 50 miles long, depending on variables like body and cargo weight, terrain, wind direction, and pedal assist level.

13Ah

50 miles (80 Kilometers) Max Range

6.5 Hours Charge Time

STRIKING COLORS AND AESTHETICS

Stunning design and a range of accent colors

With its sleek and functional design and striking paint schemes and accent colors, the Summit 27.5 looks as stunning as it rides.

Fixed, Backlit, Monochrome LCD display

The cockpit features an all new large display, with a backlight for clear visibility during night rides, increasing your safety and control.

Strong Hydraulic Disc Brakes

Front and rear Tektro hydraulic disc brakes provide consistent, controlled stops in all conditions, and prolong rim life.

Powerful Das-Kit 500W Motor

The powerful 500W Das-Kit Motor peaks at 750 watts and provides a peppy ride that will climb hills faster and accommodate riders of all sizes.

CST Rock Hawk Knobby Tires

The CST Rock Hawk knobby tires provide grip and traction for all your off-road adventures.

Shimano Acera Gear System 24 Speed 3×8

The Shimano Acera 8 Speed drivetrain provides a wide range of gears to accommodate steep trails and rough terrain.

Comfortable front suspension fork

The SR Suntour XCT ATB Spring Suspension Fork has 80mm of travel for a plush ride.

Component Overview

Motor Brand

Das-Kit

Motor Type

Geared Rear Hub

Motor Nominal Output

500 Watts

Motor Peak Output

750 Watts

Battery Voltage

48 Volts

Battery Ah

13Ah

Battery Wh

624Wh

Battery Chemistry

Li-NMC

Battery Charge Time (from empty)

6.5 Hours

Minimum Range

25 Miles (40 Kilometers)

Maximum Range

50 miles (80 Kilometers)

Display Type

Das-Kit C7, Backlit, Monochrome LCD

Display Readouts

Power Output Indicator(6 Bars), Battery Level (6 Bars), Speed, Assist Level (0-6), Odometer, Trip Distance, Trip Time, Battery Voltage

Drive Mode

Cadence Sensing Pedal Assist, Trigger Throttle, Walk Mode

Top Speed

25 mph with Pedal Assist, 20 mph with Throttle

Lights

Frame material

Aluminum Alloy

Frame Type

Fork Details

SR Suntour XCT ATB 27.5”

Gearing details

Shimano 8-Speed

Shifter Details

Shimano 8-Speed

Crank

Prowheel 3-Chainring Aluminum Alloy

Pedals

Wellgo

Stem

Adjustable w/tools

Brakes

Tektro Hydraulic Disc Brakes

Grips

Velo Flat Rubber

Saddle

Promax

Tire Brand

CST Rock Hawk

Wheel size

27.5”

Fenders

Not Included

Chain

KMC

Seat Tube

18” (46 cm)

Reach

15.75” (40 cm)

Stand Over Height

34.25” (87 cm)

Virtual Top Tube Length

23.25” (59 cm)

Min Saddle Height

21.75” (55 cm)

Max Saddle Height

30” (76 cm)

Width

30” (76 cm)

Wheelbase

44” (112 cm)

Length

73.25” (186 cm)

Total Weight

Battery Weight

Recommended Minimum Rider Height

Max Load Capacity

300 lbs. (140 kg)

Kickstand

Center-Mounted Single Side Kickstand

Bell

Included

Charger

48V / 2A

Front Rack

N/A

Rear Rack

Not Included

Fenders

Not Included

Accessory Mounts

Fender Mounts, Rear Rack Mount

Summit 27.5" videos

  • Video Review

Electric Bike Report's Review of the Magnum Summit 27.5”

Electric Bike Report does an in-depth review of the Magnum Summit from Denver, Colorado. Features highlighted are the high capacity battery pack, fully integrated into the downtube for a streamlined and stealthy appearance, 95nm of torque from the rear hub motor, ebike-specific hydraulic disc brakes, a 24 speed drivetrain for tackling any terrain, trail-ready with an SR Suntour suspension fork, and mount points for racks, fenders, and other commuting accessories.
