Whether meeting friends at the park or going for a family ride, you need an electric bike that can keep up.
The heart of the Magnum Metro S is the integrated, long-range 48V / 13Ah / 624Wh battery that powers up to 50 miles, depending on variables like body and cargo weight, terrain, wind direction, and pedal assist level.
ALUMINUM STEP THROUGH FRAME
Easily mount and dismount.
The step-through frame is easy to mount and dismount, is made of strong and lightweight aluminum, and is ideal for riders with mobility or flexibility issues.
The backlit LCD cockpit display lists: Battery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, and Trip Time.
Powerful front and rear disc brakes provide consistent, controlled stops in all conditions, and prolong rim life.
The front suspension fork offers a smooth ride on rough pavement or gravel roads, and offers a lockout feature for a stiffer ride.
Front and rear lights are integrated with the main battery and may be turned on at the cockpit display.
Wide, comfortable 26 x 2.4” tires offer a smooth ride and have a reflective strip for added safety.
Motor TypeRear Hub-Drive
Motor Nominal Output500 Watts
Motor Peak Output750 Watts
Battery BrandSamsung Cells
Battery Voltage48 Volts
Battery Charge Time (from empty)6.5 Hours
Minimum Range25 Miles (40 Kilometers)
Maximum Range50 miles (80 Kilometers)
Display TypeMagnum Branded VeloFox, 8 x 7 cm. Display Screen, Backlit Monochrome LCD
Display ReadoutsBattery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, Trip Time
Drive ModeCadence Sensing Pedal Assist, Trigger Throttle, Walk Mode
Top Speed25 mph with Pedal Assist, 20 mph with Throttle
LightsIntegrated front and rear light controlled from the display
Frame materialAluminum Alloy
Frame size17.25” (44 cm)
Fork DetailsSuspension Fork with Lockout and Preload Adjust
Gearing detailsShimano 7-Speed
Shifter DetailsShimano 7-Speed
CrankAluminum Alloy, 52T, 170mm
BrakesMechanical Disc Brakes
GripsErgonomic Faux Leather
SaddleSelle Royal Polygel
Tire BrandBrown w/Reflective Strip 26 x 2.4
FendersFront and Rear Included
Seat Tube17.25” (44 cm)
Reach16.5” (42 cm)
Stand Over Height26.75” (68 cm)
Virtual Top Tube Length23.25” (59 cm)
Min Saddle Height23.25” (59 cm)
Max Saddle Height29” (74 cm)
Width27.25” (69 cm)
Wheelbase44” (112 cm)
Length71” (180 cm)
Total Weight62 lbs (28 kg)
Battery Weight9 lbs (4.1 kg)
Recommended Minimum Rider Height5’0”
Front RackOptional Front Rack (Not Included)
FendersFront and Rear
Accessory MountsFront Carrier, Front and Rear Fender, Rear Rack
Metro S videos
- Explore The Series
- Technical Overview
Metro Series | Overview And Differences
Our product specialist points out which specs the Metro S, Metro X, and Metro 750 have in common as well as their key differences.
In-Depth Review of the Magnum Metro S
An in-depth technical overview of the Magnum Metro S. The Metro S has a well-designed cockpit with ergonomic leather grips, a trigger thumb throttle, twist shifter, wiring harness to keep wires bundled together, and an adjustable stem. It’s a one-size-fits-all bike with powerful mechanical disc brakes and pre-load and lockout features on the suspension fork. Dive in with our in-house product specialist for a technical overview of all the essential features.
